The Mil-Spec INFORMER Squad Aiming Laser is a CLASS IIIb laser consists of a green or red visible aiming laser, a near infrared (near- IR) aiming laser, and an adjustable near-IR Illuminator. The function of the INFORMER is to provide an operator with highly collimated aiming lasers forprecision aiming and targeting visible in low light conditions and in conjunction with night vision devices for night time applications. The focusable near-IR Illuminator floods the area of interest with near-infrared light only visible when used with Night Vision Devices.The output power of the INFORMER can be adjusted from approximately 50μW to 25mW electronically across 256 intervals. In addition, the aiming lasers can be operated via user selectable switch in either a constant wave or 4Hz pulsed mode.
DESCRIPTION AND FEATURES
- Rapid active target acquisition
- ultra tight, smooth and clean. Laser beams
- True night vision compatible mode
- Adjustable output power
- Green or red visible laser options
- User selectable constant wave or pulsed modes of aiming lasers
- Two tactical remote switches (including SAFETY remote switch)
- Co-boresighted aiming lasers
- Unique ballistic differential adjustment ports
SPECIFICATIONS
Divergence
IR LASER - 0.5 mRad VISIBLE LASER - 0.5 mRad IR ILLUMINATOR - 1-108 mRad
Battery type
One (1) CR123 3.0VDC lithium battery
Class
IR LASER - IIIb (near IR) VISIBLE LASER - IIIr IR ILLUMINATOR - IIIb (near-IR)
Output power
IR LASER - 50 μW (Low) 25 mW (High) VISIBLE LASER - <5.0 mW IR ILLUMINATOR - 500 μW (Low) 25 mW (High)
Operating distance
IR LASER - > 200 m (Low)>2,000 m (High) VISIBLE LASER - > 25 m in direct sunlight IR ILLUMINATOR - > 100 m (Low) >2,000 m (High)
Wavelength
IR LASER - 820 nm–860 nm VISIBLE LASER - Red 605 nm–665 nm, Green 500 nm–530 nm IR ILLUMINATOR - 820 nm - 860 nm
Battery life
>10 hours in near-IR Aim Mode
Operating Temperature
-51°C to 57°C
Storage Temperature
-57°C to 85°C
Waterproof
Upto 20m for 1 hour
Weight
0.2 kg ( 0.44 lbs)
Color (housing)
Black or Tan
Overall dimensions
106 x 81 x 48 mm (4.2 x 3.2 x 1.9 in)
