SPI ARROW T640-75-B

THERMAL MONOCULARS | PART #T640-75-B

CHARACTERISTICS

Resolution: 640 × 480
Lens: 75mm F1.0
FOV: 8.2° x 6.2° (H x V)

PACKAGE INCLUDES

  • Packing Box
  • Wrist Strap
  • Neck Lanyard
  • Lens Tissue
  • One Lithium Battery CR123A
  • Operators Manual
  • Soft Carrying Case
Thermal Binocular laser range finder IR hd military grade

DESCRIPTION AND FEATURES

Superior image quality and sensor sensitivity for rough environment. Locate point of interest with LRF in the 2 km range and acquire its coordinates, azimuth and elevation. Locate point of interest with LRF in the 2 km range and acquire its coordinates, azimuth and elevation. Endurance of equipment provides successful mission. Available in Olive green, Desert sand or Navy gray. Quick transformation into wireless (WIFI, 3G) remote control stationary system with tripod and remote control unit.

  • New high resolution, 640 x 480 LWIR Microbolometer, Extra High Sensitivity 40 mk
  • Integrated Laser Range Finder (LRF), Digital compass and GPS
  • Laser pointer
  • Designed for rough environment MIL-STD-810, IP67
  • Convenient case color
  • Remote control, motorized tripod

SPECIFICATIONS

Resolution 640×480 px
Detector pitch 17μm
Lens 75mm F1.0
FOV(8.2° x 6.2°)
Frame rate 9 / 25 fps
Export restricted 25 fps only
NETD < 40mK
Switch-on time 3 sec
Environment Certified to IP67 / MIL-STD-81OF
Automatic Calibration Yes
Temperature range -25° to +55°C
Zoom Continuouus up to x8
Poiarity W/B/C
Focus Electromic Focus
Covert/Standby Mode Yes
Display Type Dual LCD/Oled 800×600
Video Out Composite (PAL/NTSC)
Remote Control capability Yes
Power / Battery Life Rechargeable Battery 7,2V, (7-10h)
Exteranl Power 9-36V DC
Weight net / with battery 1150g/1450g
Built-In LRF 905/1550nm, 2 km range
Built-In DMC Auto/manual calibration
Built-In GPS/GLONASS Yes
Built-In Video recorder PAL/NTSC, Compression H.264, 64GB
Built-In CCTV Zoom 36x
Remote control unit Wire, Wireless (WIFI & 3G)
Built-In Laser pointer Up to 2km
